H e a v y  Du t y  .  M i l  S p e c  I n d u s t r i a l  S h o c k  C o r d

Heavy Duty Resistance Shock Cord

• natural rubber core
• single Nylon jacket or double Nylon over cotton Mil-Spec jacket
• optional Sewn Nylon Webbing End Loops
• loops are 4" (10 cm) each
• length selection includes the loops
• due to stretching during fabrication, cord including Nylon end loops may measure longer than specified relaxed length however, ultimatre stretch to strength ration remains as specified
• custom lengths available

• fabricated to order, allow 10 days to 3 weeks


---

12 mm Double Jacket Mil Spec

• Nylon over cotton double jacket
• live load rated
• 100% elongation @ 175-250 lbf
• minimum breaking strength 400 lbf @ 140% elongation
• mil spec properties

• black

20 ft (3 m) cut length $83.00 include loops $123.00	25 ft (7.6 m) cut length $100.00 include loops $140.00	Select Length 20 ft Cut Length 20 ft Add Loops 25 ft Cut Length 25 ft Add Loops 50 ft Cut Length 50 ft Add Loops 100 ft Cut Length 100 ft Add Loops
50 ft (15.2m) cut length $185.00 include loops $225.00	100 ft (30.2m) cut length $353.00 include loops $393.00

---

15 mm Single Jacket

• Nylon jacket
• not for live loads
• 100% elongation @ 150-200 lbs (68 kg-90 kg)
• minimum breaking strength 600 lbf (272 kgf) @ 140% elongation
• black



10ft (3m) cut length $80.75 include loops $120.75		20ft (6m) cut length $146.75 include loops $186.75		25ft (7.6m) cut length $180.00 include loops $220.00	Select Length 10 ft Cut length 10 ft Add Loops 20 ft Cut Length 20 ft Add Loops 25 ft Cut Length 25 ft Add Loops 50 ft Cut Length 50 ft Add Loops 100 ft Cut Length 100 ft Add Loops Select Cord Color Black White With Black Tracer
50ft (15m) cut length $343.00 include loops $383.00		100ft (30m) cut length $675.00 include loops $715.00

---

15 mm Double Jacket Mil Spec

• Nylon over cotton jacket
• live load rated
• 100% elongation @ 250-350 lbs (113,3 kg-158,7 kg)
• minimum breaking strength 1000 lbf (453,5 kgf) @ 140% elongation
• mil spec properties
• black or white with black tracer

8 ft (2.4 m) cut length $96.50 include loops $136.50		10 ft (3 m) cut length $117.00 include loops $157.00		20 ft (6 m) cut length $220.00 include loops $260.00	Select Length 8 ft Cut Length 8 ft Add Loops 10 ft Cut length 10 ft Add Loops 20 ft Cut Length 20 ft Add Loops 25 ft Cut Length 25 ft Add Loops 50 ft Cut Length 50 ft Add Loops 100 ft Cut Length 100 ft Add Loops Select Cord Color Black White With Black Tracer
25 ft (7.6 m) cut length $269.00 include loops $309.00		50 ft (15.2 m) cut length $520.00 include loops $560.00		100 ft (30 m) cut length $1,030.00 include loops $1,070.00

---

19 mm Single Jacket

• patented design manufactured in the usa
• Nylon jacket
• not for live loads
• 100% elongation @ 240 lbs (108,8 kg)
• Minimum breaking strength 800 lbf (362,8 kgf) @ 120% elongation
• black or white with black tracer

8ft (2.4m) cut length $87.00 include loops $127.00		10ft (3m) cut length $105.00 include loops $145.00		20ft (6m) cut length $195.00 include loops $235.00	Select Length 8 ft Cut Length 8 ft Add Loops 10 ft Cut length 10 ft Add Loops 20 ft Cut Length 20 ft Add Loops 25 ft Cut Length 25 ft Add Loops 50 ft Cut Length 50 ft Add Loops 100 ft Cut Length 100 ft Add Loops Select Cord Color Black White With Black Tracer
25ft (7.6m) cut length $240.00 include loops $280.00		50ft (15m) cut length $460.00 include loops $500.00		100ft (30m) cut length $910.00 include loops $950.00

---

19 mm Double Jacket Mil Spec

• patented design manufactured in the usa
• Nylon over cotton jacket
• live load rated
• 100% elongation @ 400-650 lbs (181,4 kg-294,8 kg)
• Minimum breaking strength 1000 lbf (453,5 kgf) @ 120% elongation
• mil spec properties
• black or white with black tracer

5ft (1.5m) cut length $84.00 include loops $134.00		6ft (1.8m) cut length $109.00 include loops $159.00		8ft (2.4m) cut length $140.00 include loops $180.00	Select Length 5 ft Cut Length 5 ft Add Loops 6 ft Cut Length 6 ft Add Loops 8 ft Cut Length 8 ft Add Loops 10 ft Cut length 10 ft Add Loops 20 ft Cut Length 20 ft Add Loops 25 ft Cut Length 25 ft Add Loops 50 ft Cut Length 50 ft Add Loops 100 ft Cut Length 100 ft Add Loops Select Cord Color Black White With Black Tracer
10ft (3m) cut length $172.00 include loops $212.00		20ft (6m) cut length $327.00 include loops $367.00		50ft (15m) cut length $795.00 include loops $835.00
100ft (30m) cut length $1,575.00 include loops $1,615.00

---

25 mm Double Jacket Mil Spec

• patented design manufactured in the usa
• Nylon over cotton jacket
• live load rated
• 100% elongation @ 650 lbs-950 lbs (294,8 kg-430,9 kg)
• Minimum breaking strength 1500 lbf (680 kgf) @ 120% elongation
• mil spec properties
• black or white with black tracer


3ft (91cm) cut length $80.00 include loops $120.00		4ft (122cm) cut length $100.00 include loops $140.00		5ft (1.5m) cut length $123.00 include loops $163.00	Select Length 3 ft Cut Length 3 ft Add Loops 4 ft Cut Length 4 ft Add Loops 5 ft Cut Length 5 ft Add Loops 6 ft Cut Length 6 ft Add Loops 8 ft Cut Length 8 ft Add Loops 10 ft Cut length 10 ft Add Loops 20 ft Cut Length 20 ft Add Loops 25 ft Cut Length 25 ft Add Loops 50 ft Cut Length 50 ft Add Loops 100 ft Cut Length 100 ft Add Loops Select Cord Color Black White With Black Tracer
6ft (1.8m) cut length $144 include loops $184.00		8ft (2.4m) cut length $187.00 include loops $227.00		10ft (3m) cut length $230.00 include loops $270.00
20ft (6m) cut length $443.00 include loops $483.00		25ft (7.6m) cut length $550.00 include loops $590.00		50ft (15m) cut length $1,090 include loops $1,130.00
100ft (30m) cut length $2,165.00 include loops $2,205.00

High Abrasion Resistance Shock Cord

• manufactured in the usa
• 10 mm Polyester over cotton double jacket
• maximum elongation 120% (2.2 x static) @ 40 lbs
• ideal for running through pulley systems or around smooth blocks
• available with hog ring end loops for light duty or sewn Nylon webbing end loops for heavy duty applications
• not to suspend live loads
• non refundable

3 ft hog ring loops $28.00 3 ft webbing loops $55.00		4 ft hog ring loops $32.00 4 ft webbing loops $58.00		5 ft hog ring loops $34.00 5 ft webbing loops $62.00	Select Length And Loop Option 10 mm 3 ft Hog Ring Loops 10 mm 3 ft Webbing Loops 10 mm 4 ft Hog Ring Loops 10 mm 4 ft Webbing Loops 10 mm 5 ft Hog Ring Loops 10 mm 5 ft Hog Ring Loops 10 mm 6 ft Hog Ring Loops 10 mm 6 ft Webbing Loops 10 mm 8 ft Hog Ring Loops 10 mm 8 ft Webbing Loops 10 mm 10 ft Hog Ring Loops 10 mm 10 ft Webbing Loops 10 mm 12ft Hog Ring Loops 10 mm 12ft Webbing Loops
6 ft hog ring loops $37.00 6 ft webbing loops $64.00		8 ft hog ring loops $43.00 8 ft webbing loops $68.00		10 ft hog ring loops $49.00 10 ft webbing loops $74.00
12 ft hog ring loops $55.00 12 ft webbing loops $81.00

Resistance Shock Cord Sewn Loop

• manufactured in the usa
• elastic ring of multiple strands of natural rubber wound in to a circular skein
• high grade braided yarn jacket
• meets MIL-C-5651B, Type II Mil Spec

1/2" x 9-7/8" 400 lbs $36.00		9/16" x 4-1/4" 400 lbs $47.00		9/16" x 9" 425 lbs 48.00	Select Size 8097 1/2" x 9 7/8" 9044 9/16" x 4 1/4" 9090 9/16" x 9" 9010HD 9/16" x 10" 1080 5/8" x 8" 1280HD 5/8" x 8"
HD 9/16" x 10" 475 lbs $50.00		5/8" x 8" 7850 lbs $52.00		HD 3/4" x 8" 950 lbs $55.00
