Gas
Powered Capstan
Winch 4000
- control
and hold a load flawlessly while winching
- equipped
with a centrifugal clutch, the drum does not immediately start turning
at the start of the engine
- after
having done a few wraps of rope on the drum, all that is left to do is
to insert it in the cam cleat, pass it on the exit guide and pull on it
when the time comes
- this
action then engages the centrifugal clutch and the winch starts pulling
- hoisting speed:
44 ft (13,4 m) per min
with 76 mm capstan drum
- View
More
Details...
- as soon as the tension on
the rope is released, the drum stops turning and the anti rollback
mechanism does its job by holding the load in position
- to free the rope, a simple
lateral movement is all that is needed,giving the user perfect control
throughout the pulling operation
- warranty for commercial use
- 1 year
Winch
Specs
pulling
force of 2,200 lb
without mechanical advantage
weight: 26.5 lb
length: 16-1/2 in
width: 11-3/4 in
height: 11-3/4 in
maximum pulling force 2,220
lb
Engine/Gear
Box Specs
Honda
GX50 4-stroke - 360° inclinable air-cooled 1.47 kW - 2.0 HP @
7000 tr/min
clutch : centrifugal
gear box and gears : aluminium
alloy, heat treated 3-stage helical & spur gears, mounted on
ball bearings, oil bath lubrication
gear ratio : 200:1
brake : anti-reversing roller
clutch bearing
work cycle : continuous
Rope
Specs
length
: unlimited
use double braided low stretch
7/16" (11 mm) rope (not included)
Anchor Specs
polyester
sling 60 mm x 2 m (PCA-1260) included
$1,800.00
Allow
2-3 weeks
